1. Definition

A Military-Grade Relays is an electrically operated switch used to control a circuit by a separate low-power signal or when several circuits must be controlled by one signal.

Military-grade relays are specifically designed for use in military and aerospace applications where high reliability, durability, and environmental resistance are critical. These relays are used in defense systems, aviation, space technology, and naval equipment.

2. Classification

By Operating Principle

• Electromagnetic Relays: Use magnetic force to mechanically operate contacts.
• Solid-State Relays (SSR): Use semiconductor devices to switch without moving parts.
• Thermal Relays: Triggered by heat, often used for motor protection.
• Reed Relays: Use a magnetic field to control contacts in a hermetically sealed glass tube—fast response and good for signal switching.

By Mounting Type

• Plug-in
• Flange-mounted
• Screw-mounted
• PCB-mount

By Application

• Signal relays: For low-level signal switching.
• Power relays: For higher voltage/current switching.
• Time-delay relays, protective relays, etc.

3. Key Characteristics of Military Relays

1. High Reliability: Very low failure rates; essential for mission-critical systems.
2. EMI/RFI Resistance: Withstand electromagnetic and radio-frequency interference.
3. Environmental Resistance: Operate under extreme temperatures, vibration, humidity, and shock.
4. Excellent Electrical Performance: High insulation resistance, dielectric strength, low contact resistance.
5. Long Life Span: Much higher mechanical and electrical life compared to commercial relays.

4. Typical Applications

• Aerospace: Flight control systems, power distribution, navigation systems.
• Naval Systems: Fire control, radar switching, onboard communication.
• Missile Systems: Circuit control for propulsion and guidance.
• Military Communications: RF switching, power isolation, circuit protection.
• Nuclear and High-voltage Systems: Safety interlocks, emergency cutoff systems.

5. Relevant Standards

Military relays must comply with strict standards, such as:

• GJB: Chinese military standards (e.g., GJB 548B, GJB 598A)
• MIL-STD: U.S. military standards (e.g., MIL-PRF-39016, MIL-R-6106)
• QJ: Aerospace industry standards in China
• RTCA/DO-160: Environmental standards for avionics (partially applicable)

6. Key Selection Factors

• Operating voltage and current
• Load type (resistive, inductive, capacitive)
• Contact configuration (SPST, SPDT, DPDT, etc.)
• Contact rating and life expectancy
• Response time
• Environmental specifications (temperature, humidity, shock, etc.)
• Packaging and mounting form
