Stackable 10000 Watt solor system – M48100P-LWD | High-efficiency, expandable energy storage solution for residential and commercial applications
Key Features
- Stackable Design – Free combination for flexible capacity expansion
- High Efficiency – 10.5KW rated power with 21KW peak capacity
- Pure Sine Wave Output – Clean power for sensitive electronics
- Dual MPPT Tracking – 99.9% tracking efficiency for optimal solar harvest
- Intelligent BMS Protection – Advanced battery management for safety and longevity
- Premium Battery Cells – A-grade LiFePO4 or lead-acid battery options
- Flexible Configuration – Supports up to 4 parallel units for expanded capacity
- Industrial UI Design – Intuitive interface for easy monitoring and control
Technical Specifications of Stackable 10000 Watt solor system
| Inverter Output | |
|---|---|
| Rated Output Power | 10.5KW |
| Max. Peak Power | 21KW |
| Rated Output Voltage | L+N+PE 208/220/230/240Vac (adjustable) |
| Output Waveform | Pure sine wave |
| Switching Time | 10ms (typical) |
| Number of Parallel Units | 4 |
| Battery Specifications | |
| Battery Type | Lead-acid battery/LiFePO4 |
| Rated Battery Voltage | 51.2V |
| Voltage Range | 41.6-58.4V |
| Individual Battery Pack Capacity | 5120Wh |
| Max. Charging Current | 1C |
| Photovoltaic Input | |
| Number of MPPT Paths | 2 |
| Maximum Input Power | 11000W |
| Maximum Input Current | 36A |
| MPPT Voltage Range | 120-450Vdc |
| MPPT Tracking Efficiency | 99.9% |
| General Specifications | |
| Dimensions | 555×440×915mm |
| Protection Level | IP21 |
| Operating Temperature | -20°C to 55°C (derated above 40°C) |
| Cooling Method | Built-in fan |
| Warranty | 2 years |
Why Choose Our Stackable 10000 Watt Solar System?
The M48100P-LWD stackable solar energy system offers unparalleled flexibility and performance for both residential and commercial applications. With its modular design, you can start with a single 10.5KW unit and expand your system as your energy needs grow, supporting up to 4 parallel units for massive 42KW peak capacity.
Featuring industry-leading 99.9% MPPT tracking efficiency and 93% battery inverter efficiency, this system maximizes your solar energy harvest while minimizing losses. The pure sine wave output ensures compatibility with even the most sensitive electronic equipment, while the intelligent BMS protection safeguards your investment in battery storage.
Whether you’re looking for reliable backup power, off-grid energy independence, or commercial-scale solar storage, the stackable M48100P-LWD system provides a future-proof solution that grows with your needs.
